Description
The Alpine HDA-M80 Status Series Mono Subwoofer Amplifier delivers impressive power, with 800 watts RMS at 2 ohms, for pure and undistorted sound. Enjoy deep, intense bass that brings your music to life.
Features
- Plays high-resolution music at a high quality, studio like level paired with a low frequency impact
- Power handling up to 800 watts RMS
- The tuning controls are protected by a removable top panel
- Includes adjustable low-pass, subsonic, and bass boost controls that shape the amplified signal to match your specific subwoofer, for the best sound possible
- All connections can be found on one side of the amp with speaker and wire plugs, making install or removal easy
Specs
- RMS Power Output (Watts x Channels): 500 x 1
- Power at 2 Ohms (Watts x Channels): 800 x 1
- Minimum Impedance Unbridged: 2
- Minimum Impedance: 2
- Frequency Response: 8-400 Hz
- THD at Rated RMS Power: 0.07%
- Signal to Noise Ratio: 107 dB
- Input Voltage: 14.4v
- Amplifier Class: D
- Low-Pass Crossover Frequency: 50-400 Hz
- Low-Pass Slope (dB/octave): 24 dB/octave
- Bass Boost: 0-12 dB
- Bass Boost Frequency: 50 Hz
- Fuse Rating: 90
- Preamp Outputs: 2
Dimensions
- Size H x W x D: 1.9” x 10.5” x 6.5”
What’s in the Box
- Alpine Status Series Mono Subwoofer Amplifier, 800 watts RMS at 2 ohms
