Savox SV-1260MG Digital High-Voltage Servo Featuring Coreless Motor and Durable Metal Gears

Description

SV-1260MG Savox – Servo – SV-1260MG – Digital – High Voltage – Coreless Motor – Metal Gear

SV-1260MG
Savox – SV-1260MG Digital High Voltage Coreless Motor Servo, Metal Gear
Features:
– Leading edge digital servo technology
– High efficiency Coreless motor
– Accurate and fast response
– Super high resolution
– Aluminium center case for improved motor cooling and total strength
– Ball beared
– Precision Metal gears
Technical specifications:
Servo Technology: Digital High Voltage
Input Voltage (V): 6.0V – 7.4V
Servo Type / Size: Midi
Motor Type: Coreless Motor
Gear Material: Metal Gears
Ball Beared: Ball Beared
Servo Case: Aluminium – Composite
Speed 60°/Sec @ 7.4V: 0.055 Sec/60°
Torque kg/cm @ 7.4V: 12.0 Kg/cm
Length (mm): 35.0 mm
Width (mm): 15.0 mm
Height (mm): 30.7 mm
Weight (g): 29.5 g
Connector type: JR
Spline size: 25T Spline
