RS-R Coilover Suspension Kit for 2022+ Subaru Outback

Description

Part Number: XBIJF670M Compatibility: 2022+ Subaru Outback Chassis code:

Product Details

Part Number: XBIJF670M Compatibility: 2022+ Subaru Outback Chassis code:

Preset Approximate Height

Front: +5mm to 0mm (+0.2in to 0in) Rear: +5mm to 0mm (+0.2in to 0in)

Maximum Adjustment Range

Front: +30mm to -60mm (+1.2in to -2.4in) Rear: +30mm to -50mm (+1.2in to -2.0in)

Recommended Adjustment Range

Front: +25mm to -45mm (+1.0in to -1.8in) Rear: +25mm to -30mm (+1.0in to -1.2in)

Spring Rate

Front: 7.00kg/mm Rear: 7.00kg/mm

Additional Information

Warranty: 1 Year / 12,000 miles from the day of purchase Dampers are 36 way adjustable in the front and 24 in the rear Included but not pictured: hex and allen wrench, mount adapter for rear, and spring tubes for front and rear

Specification

Weight: 68 lbsDimensions: 13 in x 30 in x 13 in

Compatibility

Make: SUBARU Model: Outback Years: 2022, 2023, 2024
