Fan28591 12V DC 75A 900W Power Supply with USB Output

Description

12 VOLT DC POWER SUPPLY – 75 AMP / 900 WATTS WITH 5 VOLT – 3 AMP USB PORT

Get the most out of your battery charger with this high-performance power supply. It provides enough clean, reliable power to charge your batteries at even the most demanding charge rates that today’s high-end chargers are capable of.

More Power to the People…

Here’s the formula to determine how much power you need:

• Battery Pack Voltage x Desired Charge Rate (Amps) = Watts Needed

Example 1:

• 7.4v 2-cell LiPo x 20 amp charge rate = 148 watts required from power supply

Example 2:

• (Dual Charger) 2 x 7.4v 2-cell LiPo’s x 20 amp charge rate = 296 watts amps required from power supply

SPECIFICATIONS:

• INPUT VOLTAGE – 100v to 240v AC (50 – 60 Hz)
• OUTPUT VOLTAGE – 12.25v DC
• OUTPUT CURRENT – 75A Max
• OUTPUT WATTS – 900W Max
• 5 volt – 3 amp USB Port
• DIMENSIONS – 8.5 (9.75 w/ handle) x 3.5 x 1.5″ Inches
• WEIGHT – Approx. 2.25 pounds

FEATURES:

• 5 volt – 3 amp USB Port
• Over-Voltage Protection
• Low-Voltage Protection
• Over-Current Protection
• Over-Temperature Protection
• Short Circuit Protection
• 3 Sets of 4mm Female Gold Bullet Output Connectors
• Cooling Fan w/ Auto Fan Speed
• Completely Vinyl Wrapped with Premium Material and Fantom Graphics
• Includes Protective Cover to Protect Connectors
• Includes 6-foot Heavy-Duty Power Cord
• Handle
• Rubber Feet

WARNING: Do not connect power supplies together in series to produce more voltage. This can cause permanent damage to your power supply and/or charger, which is not covered under warranty.
