Double-Drilled Rear Brake Rotor for Volkswagen Beetle and Ghia (5-Lug Pattern)

Description

REAR Brake Rotor

Sold Individually

Type 1 Bug 1949 Thru 1968 Swing Axle With Empi Disc Brakes Listed Below
Type 1 Karmann Ghia 1956 Thru 1968 Swing Axle With Empi Disc Brakes Listed Below
Type 1 Bug 1968 Thru 1979 I.R.S. With Empi Disc Brakes Listed Below Requires Empi Spacer #22-5281-7
Type 1 Super Beetle 1971 Thru 1979 I.R.S. With Empi Disc Brakes Listed Below Requires Empi Spacer #22-5281-7
Type 1 Karmann Ghia 1968 Thru 1974 I.R.S. With Empi Disc Brakes Listed Below Requires Empi Spacer #22-5281-7
Replacement Rotor For:
Empi Disc Brake Kit 22-2910
Empi Disc Brake Kit 22-2910-F
Empi Disc Brake Kit 22-2911
Empi Disc Brake Kit 22-2911-F
Empi Disc Brake Kit 22-2912
Empi Disc Brake Kit 22-2912-F
Empi Disc Brake Kit 22-2913
Empi Disc Brake Kit 22-2913-F
Empi Disc Brake Kit 22-2914
Empi Disc Brake Kit 22-2914-F
Specs:
Double Drilled 5 Lug X 130mm Porsche Lug Bolt Pattern (14mm X 1.5 Threads)
Double Drilled 5 Lug X 4-3/4″ Chevy Lug Bolt Pattern (12mm X 1.5 Threads)
11″ Overall Diameter
3-1/2″ Depth
Note: Short Spline Type Rotor For Swing Axle. Can Also Be Used With I.R.S. 1968 Thru 1979 Requires Empi Spacer #22-5281-7 For I.R.S. Applications

Our Reference: 22-2843-7
R16/24
